The JV100 Standard Drag Box from Altrad Generation is a protective shield designed for pipe laying and excavation work in self-supporting soil conditions. Rather than acting as a structural support, the drag box moves with the work, protecting operatives as progress advances along the trench.
Installation follows the Excavate and Drag method: the box is positioned in a pre-dug trench and moved forward by an excavator after each section of pipe is installed. The standard configuration includes four struts and integrated lifting points for safe slinging. The JV100 is rated to 25kN/m2 and is available in 5m and 7m lengths.
Edge Safe Systems and a Ladder Access System are available as optional additions. The JV100 is compatible with Altrad Generation Manhole Boxes for combined applications.
Key Features and Benefits
Rated to 25kN/m2 for use in self-supporting soil conditions
Installed using the Excavate and Drag method
Standard configuration includes four struts
Integrated lifting points for safe slinging
Available in 5m and 7m lengths
Edge Safe Systems available as an optional addition
Ladder Access System available as an optional addition
Compatible with Altrad Generation Manhole Boxes
Frequently Asked Questions
Q: What is a drag box used for?
A: A drag box protects workers during pipe laying and excavation in self-supporting soil. Rather than shoring the trench walls, the drag box moves along the trench as a shield, keeping workers safe while pipe installation progresses.
Q: How is the JV100 Standard Drag Box installed?
A: The JV100 uses the Excavate and Drag method. An excavator pre-digs the trench, the box is placed in position, and after each section of pipe is installed, the excavator drags the box forward to the next position.
Q: What ground conditions suit a drag box?
A: Drag boxes are designed for self-supporting soil conditions. Where ground is unstable or services are present, a trench box or manhole brace is the correct choice. Always seek a design review if conditions are uncertain.
Q: What sizes is the JV100 available in?
A: The JV100 Standard Drag Box is available in 5m and 7m lengths.
Q: Are edge protection and ladder access available for the JV100?
A: Yes. Edge Safe Systems and a Ladder Access System are available as optional additions for the JV100 Standard Drag Box. Contact your nearest branch for full specification details.
