Steel Jaw Clamp MK2
The Steel Jaw Clamp MK2 is a versatile scaffold clamp designed to fix Combisafe safety posts to steel beams and columns on construction sites. At 7.9 kg, the clamp body features adjustable jaw positions and a repositionable spacer that increases the offset between the clamp and the post fixing point. This means the same unit works on a range of steel section sizes, reducing the number of different scaffold fittings a site team needs to hold in stock.
The adjustable jaw configuration allows the Steel Jaw Clamp MK2 to fix in both horizontal and vertical planes, making it suitable for beam flange fixing and column face fixing without requiring a separate product. This dual-plane capability is a practical advantage on steel frame construction projects where beams and columns of varying section sizes are encountered on the same floor level.
Beam clamp scaffolding components that can be repositioned without specialist tools reduce installation time and allow edge protection to track the advancing steel frame. The repositionable spacer on the Steel Jaw Clamp MK2 provides the additional offset needed when the clamp body position alone does not place the post at the correct geometry for the barrier. Altrad Generation hires and sells the Steel Jaw Clamp MK2 across its UK and Ireland network.
Key features and benefits
Adjustable jaw positions allow fixing to steel beams and columns of varying section sizes
Repositionable spacer increases offset distance for geometry situations where standard jaw position is insufficient
Suitable for both horizontal and vertical fixing planes without requiring a separate product
7.9 kg unit weight is manageable by site operatives during installation on the steelwork
No permanent fixings required, leaving the structural steel unmarked when the clamp is removed
Works across a range of steel section sizes, reducing the range of scaffold fittings needed on site
Compatible with Combisafe Safety Posts and Steel Mesh Barrier panels
Available on hire or for purchase through Altrad Generation's UK and Ireland branch network
Frequently asked questions
Q: How do you fix edge protection to a steel column?
A: The Steel Jaw Clamp MK2 is designed for fixing edge protection to both steel beams and columns. The adjustable jaws grip the column flange or web face, and the repositionable spacer provides offset where the geometry requires the post to stand away from the column face. The clamp is positioned in the horizontal or vertical plane depending on the column orientation, and a Combisafe Safety Post is then inserted into the clamp body to receive the Steel Mesh Barrier panels.
Q: What is a jaw clamp used for in scaffolding?
A: A jaw clamp in scaffolding grips a steel section, such as a beam or column flange, using a pair of opposing jaw faces that are tightened onto the steel. Unlike a multi-clamp, which wraps around the full beam flange, a jaw clamp grips the underside or face of the flange, making it suitable for sections where the full flange width is not accessible. The Steel Jaw Clamp MK2 provides adjustable jaw spacing to accommodate different section sizes and a repositionable spacer for offset fixing.
Q: Can scaffold clamps be used on both beams and columns?
A: The Steel Jaw Clamp MK2 is designed for use on both beams and columns. The adjustable jaw positions and repositionable spacer allow the same unit to be configured for beam flange fixing and column face fixing. On columns, the spacer is typically repositioned to offset the post away from the column face, creating the clearance needed for the barrier to sit correctly. On beams, the standard jaw position is used for flange gripping in either the horizontal or vertical plane.
Get in touch with us
To hire or purchase the Steel Jaw Clamp MK2, contact your nearest Altrad Generation branch. Our teams across the UK and Ireland provide technical advice on the correct clamp configuration for your steelwork and deliver across both countries.
