Multi Foot
The Multi Foot is a three-point support base used to secure Combisafe safety posts at the edges of concrete slabs. The three-point design distributes the load across a wider footprint than a single-point scaffold foot, maintaining stability on uneven concrete surfaces without the need for drilling or resin anchoring. At 1.6 kg, the unit is light enough for a single operative to carry and position, speeding up the edge protection erection process.
Concrete slab edges are among the most common fall risk locations on UK construction sites. The Working at Height Regulations 2005 require duty holders to provide collective protection at slab edges wherever a fall of 2 m or more is possible. The Multi Foot combined with a Combisafe Safety Post and Steel Mesh Barrier forms a non-invasive scaffold base plate equivalent that satisfies this requirement without leaving anchor holes in the finished slab.
The adjustable support points allow the Multi Foot to level on surfaces that are not perfectly flat, a common condition on concrete slabs before floor finishes are applied. This adjustability maintains post verticality even on slabs with laitance buildups or surface irregularities, ensuring the edge protection geometry stays within EN 13374 specification throughout the project.
Key features and benefits
Three-point support distributes load across a wider footprint than single-base scaffold foot designs
Secures Combisafe safety posts at concrete slab edges without drilling, anchoring, or permanent fixings
1.6 kg unit weight allows single-operative carrying and positioning
Adjustable support points accommodate uneven concrete surfaces and surface irregularities
Maintains post verticality on slabs with laitance or pre-finish surface variation
Supports compliance with the Working at Height Regulations 2005 at 2 m-plus fall-risk locations
Compatible with Combisafe Safety Posts and Steel Mesh Barrier panels
Available as System C (code 37110) through Altrad Generation's UK and Ireland branch network
Frequently asked questions
Q: How do you secure edge protection posts at slab edges?
A: The Multi Foot three-point base secures Combisafe safety posts at concrete slab edges without drilling or chemical anchoring. The three support points are positioned on the slab surface and adjusted to achieve a level, stable base. The safety post then inserts into the Multi Foot and is locked in position. Steel Mesh Barrier panels are fitted between the posts to form the edge protection line. The three-point contact principle keeps the assembly stable even on slabs with minor surface unevenness.
Q: What is a scaffold multi foot used for?
A: A scaffold multi foot is a base support unit that holds a safety post in a vertical, stable position at the edge of a concrete slab. Unlike a standard scaffold base plate, which is used for vertical load-bearing scaffold standards, the Multi Foot is designed for the horizontal-to-vertical transition at a slab edge where a conventional base plate would overhang or be unstable. The Combisafe Multi Foot is suitable for temporary edge protection systems on new-build slabs, refurbishment projects, and structural concrete works.
Q: Can edge protection be installed on uneven concrete without drilling?
A: The Multi Foot is designed for exactly this situation. The three adjustable support points allow the base to conform to minor surface unevenness without requiring the slab to be ground level or prepared beforehand. No drilling, resin anchoring, or temporary fixings are required. The weight of the edge protection system combined with the three-point friction contact provides sufficient stability under the dynamic loads specified in EN 13374 for temporary edge protection.
Get in touch with us
To hire or purchase the Multi Foot, contact your nearest Altrad Generation branch. Our teams across the UK and Ireland provide technical advice on slab edge protection configurations and delivery of the full Combisafe system.
