More about Traffic Management

We offer a wide range of road barriers for effective traffic management across all site types. From low-level to high-duty systems, our barriers control flow, protect work zones, and enhance safety in both pedestrian and vehicle areas.

Low-Level Road Barriers
Altrad Generation offers a comprehensive range of low-level road barriers designed for safety, visibility, and durability. The Evo Barrier is MIRA wind-speed tested to withstand winds up to 55 mph when water-filled, making it ideal for exposed environments. The Trojan Barrier effectively separates work zones to support compliance and maintain safe pedestrian and vehicle routes. The Pyramid Barrier allows up to 90° rotation without the need for tools, enabling fast and flexible site boxing. The WonderWall Barrier meets both Chapter 8 and BS EN12899-1 standards, ensuring high visibility and safety on UK roads. The Buddha Barrier offers over 270° connectivity for adaptable site layouts. Finally, the Mini Bison Barrier is Chapter 8 compliant and provides a compact, durable, and easy-to-deploy solution.

Medium-Duty Road Barriers
Altrad Generation’s medium-duty barriers deliver the ideal balance of strength, versatility, and ease of use for a wide range of traffic and site safety applications. The Novus Barrier is Chapter 8 compliant and MIRA tested to withstand wind speeds up to 68 mph when ballasted, offering exceptional performance in challenging conditions. The Bison 800 Barrier also meets Chapter 8 standards and features a pin locking system that allows barriers to connect at a 90-degree angle - ideal for secure, angled layouts. The Bison Barrier is fully stackable and incorporates an anti-slide base design for safe and efficient transport and storage. Together, these barriers provide flexible and reliable solutions for mid-level traffic management needs.

Heavy-Duty Road Barriers
Designed for high-risk and high-traffic zones, Altrad Generation’s heavy-duty barriers offer robust protection and dependable performance. The GB2 Barrier features a pin locking system that enables secure connections at 35° angles, supporting custom layouts. The RB2000 Barrier is wind-speed tested up to 72 mph (when water-filled) and offers a modular design suitable for large-scale deployments. The RB22 Barrier is certified to BS EN1317 N1 crash test standards, tested at 50 mph, and provides strong interlocking performance. These heavy-duty options are engineered to ensure site security and safety in the most demanding environments.

GS6 Goal Post
Altrad Generation also offers the GS6 Goal Post which is fully compliant with HSE GS6 guidance and is designed to provide clear, early warnings of overhead hazards such as live electrical cables and structural obstructions. The post helps prevent accidental contact and improves safety for drivers and site operatives working near high-risk areas.

TRAFFIC MANAGEMENT BARRIERS MATERIALS/SIZES

Evo Barrier: We offer a wide selection of Evo Barrier components in various sizes, all manufactured from UV-stabilised prime polyethylene for long-lasting performance.

Trojan Barrier: The Trojan Barrier weighs just 5kg and measures 1000mm (L) x 525mm (H) x 300mm (W), constructed from high-density polyethylene (HDPE) for strength and durability.

Pyramid Barrier: The Pyramid Barrier measures 1000mm (L) x 555mm (H) x 400mm (W) and weighs 6kg, offering a stable, compact solution for effective traffic and pedestrian management.

Wonderwall Barrier: The Wonderwall Barrier is a strong, robust solution designed to withstand high winds without the need for additional ballasts. It measures 1140mm (L) x 1000mm (H) x 500mm (W) and weighs 18kg.

Buddha Barrier: The Buddha Barrier is manufactured from durable, 100% recyclable HDPE, measuring 1040mm (L) x 800mm (H) x 280mm (W) and weighing just 5.5kg.

Mini Bison Barrier: The Mini Bison Barrier measures 1000mm (L) x 800mm (H) x 300mm (W) and features a substantial 70kg filled weight with an impressive 60-degree rotation capability - ideal for creating curved or angled barrier layouts.

Novus Barrier: The Novus Barrier measures 2000mm (L) x 800mm (H) x 520mm (W), weighs 25kg, and is engineered from prime UV-stabilised MDPE for enhanced durability and long-term outdoor performance.

Bison 800 Barrier: The Bison 800 Barrier measures 2000mm (L) x 800mm (H) x 350mm (W) and weighs 25kg, providing a robust, high-visibility solution ideal for managing vehicle and pedestrian flow.

Bison Barrier: The Bison Barrier measures 2000mm (L) x 1000mm (H) x 400mm (W) and weighs 35kg.

GB2 Barrier: The GB2 Barrier measures 2000mm (L) x 900mm (H) x 500mm (W) and weighs 32kg with the option to add anti-climb mesh and hoarding panels to increase the overall height of the barrier.

RB2000 Barrier: The RB2000 Barrier is constructed from UV-stabilised prime polyethylene, measuring 1650mm (L) x 1000mm (H) x 400mm (W) and weighing up to 400kg to create a solid, flat walled, secure system.

RB22 Barrier: The RB22 Barrier is manufactured from prime UV-stabilised polyethylene, measuring 2000mm (L) x 800mm (H) x 500mm (W) and weighing 60kg for dependable strength and durability.

GS6 Goal Post: The GS6 Goal Post System is made from non-conductive GRP, with an adjustable height range from 1.83m to 7.53m. Supplied with either water-filled bases, poles and bunting (10kg), or metal bases, poles and bunting (55kg), offering versatile overhead protection.

 APPLICATIONS

• Road closures

• Lane delineation

• Pedestrian safety

• Event crowd control

• Construction zones

• Temporary access control

• Vehicle redirection

• School or site entrances

FAQs

Can the barriers be linked together?
Yes, many of our barriers feature interlocking or hook-and-eye systems to form continuous runs.

Do the barriers come in different weights and sizes?

We offer a comprehensive range of barriers in various sizes and weights to suit different site requirements. Height can also be increased with optional accessories such as the Double Top and different mesh panels.

Are your barriers Chapter 8 compliant?
Yes, our WonderWall Barrier, Mini Bison Barrier, Novus Barrier, and Bison 800 Barrier are all fully Chapter 8 compliant, meeting the required standards.

If you're not sure what Traffic Management Barriers you require, Contact Your Local Branch for more information. We're happy to help!
