Altrad Generation's Flexible Roadform is a robust, adaptable edge formwork system for creating smooth curves and radius work in concrete edge forming for roadways, working areas, and ground slabs. Five welded stake housings allow precise settings for any desired curvature, giving you accurate radius formwork for concrete pours ranging from gentle curves to tight radii.
Manufactured from strong square-section steel, the Flexible Roadform is designed for use alongside Altrad Generation's Standard Roadforms, together forming a complete edge formwork solution for both straight and curved concrete edges on ground slabs, roadways, pathways, and foundations up to 300mm deep. An integrated locking tongue provides continuous runs and smooth transitions between straight and curved sections.
Flexible roadform hire is available in four sizes, with depths from 150mm to 300mm and lengths of 3000mm. Weights range from 19.5kg to 46kg to suit your pour depth and site conditions.
Key Features and Benefits
Four sizes: 150mm (19.5kg), 200mm (24.2kg), 250mm (28.9kg), and 300mm (46kg) depth at 3000mm length
Square-section steel construction for strength, accuracy, and reusability across multiple pours
Five welded stake housings for stable, precise curvature settings
Integrated locking tongue for continuous runs combining straight and curved sections
Designed to work alongside Standard Roadforms for a complete edge forming system
Suitable for ground slabs, roadways, pathways, and foundations up to 300mm deep
Frequently Asked Questions
Q: What is a flexible roadform used for?
A: A flexible roadform creates the edge boundary for curved concrete pours. Five stake housings allow you to set the roadform to any desired radius, giving a smooth, accurate formwork edge for radius work on roadways, pathways, ground slabs, and foundations.
Q: What is the difference between a flexible roadform and a standard roadform?
A: Standard roadforms create straight, rigid concrete edges. Flexible roadforms bend to the required radius, allowing smooth curves and radius transitions in the concrete edge. The two systems are designed to work together on the same project.
Q: What sizes of flexible roadform does Altrad Generation offer?
A: Flexible roadforms are available in four sizes: 150mm depth (19.5kg), 200mm depth (24.2kg), 250mm depth (28.9kg), and 300mm depth (46kg). All sizes are 3000mm long.
Q: Are flexible roadforms reusable?
A: Yes. The square-section steel construction is built for repeated use across multiple pours and projects.
Q: Are flexible roadforms available for hire?
A: Yes. Flexible Roadform hire is available from Altrad Generation branches across the UK and Ireland. Contact your nearest branch for availability and pricing.
