BD500 Overlapping Trench Sheets from Altrad Generation are a robust steel sheet piling solution used to support earth banks and provide permanent reinforcement of waterway banks and service trenches. The strength, speed, and flexibility of the BD500 profile make these overlapping trench sheets hire and sale a strong choice for both temporary and permanent groundworks applications.
The durability and ease of extraction of the BD500 means the sheets are reusable across multiple projects, supporting sustainable construction practices. Available in lengths from 2000mm to 8000mm, with weights from 55.48kg to 221.94kg, the range suits a wide variety of excavation depths and soil conditions. Where a steel trench sheet structure performs the permanent function required, such as in canal construction or bank reinforcement, the BD500 eliminates the need for separate temporary works entirely.
For steel sheet piling in groundworks, the BD500 pairs with Quick Release Pitching Shackles for faster, more efficient installation. Driving Caps are available to minimise damage to sheet heads during driving, and Extraction Clamps facilitate safe, controlled removal after use.
Key Features and Benefits
Available in lengths from 2000mm to 8000mm to suit various excavation depths
Weights from 55.48kg (2000mm) to 221.94kg (8000mm)
Suitable for temporary and permanent groundworks applications
Durable and reusable, supporting sustainable construction practices
Ideal for waterway bank reinforcement and service trench support
Compatible with Quick Release Pitching Shackles for faster installation
Driving Caps available to protect sheet heads during driving
Extraction Clamps available for safe, controlled removal after use
Frequently Asked Questions
Q: What are BD500 overlapping trench sheets used for?
A: BD500 sheets support earth banks in excavations and provide permanent reinforcement for waterway banks and service trenches. They suit both temporary shoring during groundworks and permanent structural applications such as canal linings and bank stabilisation.
Q: What lengths are BD500 trench sheets available in?
A: BD500 Overlapping Trench Sheets are available in lengths from 2000mm to 8000mm, in 500mm increments. This range covers depths from shallow utility trenches to deeper excavation and permanent retaining applications.
Q: Are BD500 sheets reusable?
A: Yes. The durability of the BD500 profile and its ease of extraction make the sheets reusable across multiple projects, reducing material costs and supporting more sustainable construction operations.
Q: What accessories are recommended for BD500 installation?
A: Quick Release Pitching Shackles improve installation speed and accuracy. Driving Caps protect the sheet head during driving operations. Extraction Clamps allow for safe, controlled removal after use.
Q: Are BD500 trench sheets available for hire from Altrad Generation?
A: Yes. BD500 Overlapping Trench Sheets are available for hire and sale from Altrad Generation branches across the UK and Ireland. Contact your nearest branch for availability and pricing.
