JV100 Standard Trench Box

The Standard Trench Box is used to provide a safe working area below ground and ensure that the side walls of an excavation are continually supported.

Read full description

Select from product options

Product

Code

Weight

JV100 Standard Trench Box Base Unit Top Unit
Panel Length (mm) 3500 3500
Panel Height (mm) 2600 1500
Panel Thickness (mm) 100 100
External Trench Width (mm) 690 - 4500 690 - 4500
Internal Trench Width (mm) 490 - 4300 490 - 4300
Weight (kg) 2100 1130
Distance Between Struts (mm) 3210 3210
Clearance Below Strut (mm) 1500 -
Permissible SWL (kN/m²) 40 40

JV100 Standard Trench Box

The Standard Trench Box is used to provide a safe working area below ground and ensure that the side walls of an excavation are continually supported. Standard Trench Boxes can be used in conjunction with other boxes, including Manhole Boxes.

The Standard Trench Box can be used in trenches up to 5600mm deep with widths from 690mm to 4500mm. Up to two extension boxes can be added on top of the standard Trench Box to achieve additional depth if needed.

KEY FEATURES

  • Two-sided Support

  • Used In Conjunction With Manhole Boxes

  • Additional Top Boxes Available

  • Quick & Easy To Install

  • Dig & Push Method Used

  • Additional Equipment Available

GET IN TOUCH WITH US:

If you would like more information about this product, please Contact Your Nearest Branch.
