The BVB Backhoe Trench Box is a robust, lightweight shielding solution built for excavation and pipe-laying operations in inner-city environments and sites where lifting capacity is restricted. Designed for use with smaller machines such as 180 degrees excavators and rubber-tyred excavators, this inner city shoring box delivers safe, practical below-ground protection where standard and mini trench boxes are too heavy for the available plant.
This backhoe trench box hire option is effective to a working depth of 3.00m, provided ground pressure does not exceed 19.40kN/m2. Panels measure 3000mm long by 2000mm deep, with a width range of 720mm to 1720mm adjusted using telescopic struts secured via a pin and R-clip system. Backhoe box tops allow depth extension to 3000mm where needed.
The BVB is ideal for laying small-diameter utility pipes including gas, water, telecoms, and power cables in restricted urban excavations. The dig and push installation method keeps operatives safe and allows fast progression along a trench run.
Key Features and Benefits
Lightweight design suited to smaller excavators and restricted lifting capacity
Effective working depth up to 3.00m
Withstands earth pressures up to 19.40kN/m2
Panels: 3000mm long x 2000mm deep
Width range 720mm to 1720mm, adjusted with telescopic struts
Backhoe box tops extend working depth to 3000mm
Pin and R-clip system for fast, secure assembly on site
Dig and push installation method for safer operative positioning
Ideal for small-diameter utility pipe installation in urban environments
Frequently Asked Questions
Q: What is the BVB Backhoe Trench Box used for?
A: The BVB Backhoe Trench Box provides a two-sided shielded working area for pipe laying and utility installation in excavations. Designed for smaller machines, the box suits inner-city sites and locations where standard trench boxes are too heavy for the available lifting equipment.
Q: How deep does the BVB backhoe trench box work?
A: The BVB is effective to 3.00m working depth, provided ground pressure does not exceed 19.40kN/m2. Backhoe box tops extend the working depth to a maximum of 3000mm.
Q: How is the BVB backhoe trench box installed?
A: Installation uses the dig and push method. The excavator lowers the box into the trench and pushes to the required depth. Telescopic struts are adjusted with the pin and R-clip system to suit the trench width, keeping your operatives away from unsupported ground throughout.
Q: What types of utility pipe installation is this box suited for?
A: The BVB Backhoe Trench Box suits small-diameter pipe installation including gas, water, telecoms, and power cable routes in urban and suburban environments.
Q: Is the BVB backhoe trench box available for hire?
A: Yes. The BVB Backhoe Trench Box is available for hire and sale from Altrad Generation branches across the UK and Ireland. Contact your nearest branch for availability and pricing.
